Nominal pressure pnom : 420 bar
Peak pressure pmax : 450 bar
Displacement Vmax : 280-520 cm3/rev
?Low-noise emissions
?Full torque available at the second pump in tandem pump applications
| Displacement (cm3/rev.) | Rated pressure (bar) | Minimum oil suction pressure (bar） | Shell pressure (bar) | Self suction speed (rpm ) | Minimum speed (rpm) | Temperature range (℃ ) | Weight (kg) | |
| F30D - 280 | 280 | 420 | 0.85 | 2 | instantaneous 3 | 1800 | 500 | -25~100 | 131 |
| F30D - 520 | 520 | 420 | 0.85 | 1 | instantaneous 2 | 1500 | 500 | -25~100 | 252 |
