Specifications: 28
Rated Pressure: 350 bar
Rated Flow: 300 L/min
High efficiency
Less volume, lighter weight
Precise controllability
Less pressure drop, low fuel consumption
Perfect flow distribution
| Specification | HVSM25 | |
| Nominal size | 28 | |
| Rated flow | Q (L/min) | 300 |
| Max. operating pressure at port | P/LS (bar) | 320 |
| A/B (bar) | 350 | |
| T (bar) | 30 | |
| TS (bar） | < 2 | |
| Pilot pressure | a/b (bar | < 35 |
| Pilot control pressure range | 8 ~ 22 bar | |
